Marelli Motori M71FA320A Digital Automatic Voltage Regulator MEC-100
4,997.00$
- PKR: ₨ 1,407,155.23
Its Used Item
Additional information
| Brand | Marelli |
|---|---|
| MPN | |
| Model | |
| Type |
1 in stock
Description
Description
USG
Marelli Motori MEC-100 M71FA320A Digital Automatic Voltage Regulator Version IS 3.0 v3
Marelli MEC-100 is a high-performance digital regulator designed for precise excitation control of synchronous generators. It is compatible with auxiliary windings, mains, and PMG power sources, offering superior accuracy and a rapid response time for industrial power stability.
Electrical characteristics:
Power supply voltage: 170 ÷ 277 Vac @ 50 ÷ 400 Hz
Power supply source: Auxiliary windings, mains, PMG
Voltage build-up: 15 Vac
Voltage sensing type: 1-phase / 3-phase
Voltage sensing range: 100 ÷ 500 Vac
Current sensing type: 1-phase
Current sensing range: 1 Aac / 5 Aac
Maximum continuative field current: 0 ÷ 10 Adc
Maximum forcing field current: 0 ÷ 20 Adc
Maximum field voltage: 250 Vdc
Field resistance: 3 Ω ÷ 20 Ω
Regulation accuracy from no load to full load: ±0.25 %
Steady state accuracy: ±0.1 %
Accuracy with ±4% engine governing: ±1 %
Accuracy in PF / VAR / FCR modes: ±2 %
Voltage matching accuracy: ±0.5 %
Thermal Drift: ±0.5 %
Response time: 1 cycle
Operating temperature: -30°C ÷ +70°C
Storage temperature: -40°C ÷ +80°C
Marelli MEC-100, MEC100 AVR, Software IS 3.0 v3, Marelli Digital Regulator, Generator Voltage Control, MEC-100 Excitation, Marelli Motori Spare Parts, Industrial AVR.
